A
multipurpose household appliance protector that
prevents electroshock and power leak, and offers
stabilized current, with voltage stabilizing function
and thundering protection.
|
|
|
● |
Effective
curtails concerns of electroshock or electric
power leak when operating electrical equipment. |
● |
Comes
with oscillation filtration function and provides
purified current allowing a host of A/V equipment
to sound and look their very best. |
● |
Come
with built-in automatic current output tracking
device to provide voltage stabilization and
effectively prevent electrical equipment from
damaged or shutdown due to malfunction arisen
from excessive power fluctuatins. |
● |
Comes
with parameter-rated short-circuit protection
device that automatically shuts down and turns
off he power when detecting a short in the
circuit to prevent fire triggered by short-circuiting. |
● |
Equipped
with auto reset device that resets by itself
when anomaly detected by the circuit has been
removed, as the electronic troubleshoot device
automatically resets in 20 seconds without
having to call for the repair technician. |
● |
Comes
with thundering protection device that prevents
circuit burnout amid sudden voltage surge
due to thundering strike, and is the only
product in the comparable grade that comes
with built-in thundering protection device,
as absorbs and protects itself. |
|
|
● |
Options
to choose the Japanese current specification
of 100 volts, or the American current specification
of 120 volts for imported appliances through
adjustable current output. |
● |
Effectively
curbs the phenomenon of pressure magnification
arisen from linking to a transformer in positive
peaks of the oscillation that might harm electronic
equipment. |
● |
Operates
on OND steel core with maximum operating efficiency,
and is compact and at low working temperatures. |
● |
Comes
with activation indicator light to prompt
the unit's current working status and state
of power consumption. |
● |
Able
to absorb and protect electronic devices amid
sparks or power surge at the receptacle. |
● |
Comes
with automatic load detection function. |
● |
Equipped
with protective device that helps to prevent
short-circuiting arisen from rupture in the
insulation wire after extended transformer
use. |
● |
The
only current regulator equipped with safety
switching device that insulates thundering. |
● |
Equipped
with ergonomically designed handle for great
portability, and is boasted as the only model
that offers switch and safe implementation
and installation.
|
|
|
Electrical
specification
|
|
High-voltage
insulation 4000VAC
Input voltage 95VAC-135VAC
Input amperage 10 Amp
Performance efficiency 94%Continuous
overload 10A/100ms
|
Gross
weight 10.5 kgs
Length 30cm
Width 18.5cm
Height 14cm
Transition cutoff 17A/10ms
|
|
|
|
|
|
